Speedometer Speedo Tachometer

6 Gauge Set With Senders 200mph 300kph Speedo Tacho Fuel Temp Volts Oil Pressure

6 Gauge Set With Senders 200mph 300kph Speedo Tacho Fuel Temp Volts Oil Pressure
6 Gauge Set With Senders 200mph 300kph Speedo Tacho Fuel Temp Volts Oil Pressure
6 Gauge Set With Senders 200mph 300kph Speedo Tacho Fuel Temp Volts Oil Pressure
6 Gauge Set With Senders 200mph 300kph Speedo Tacho Fuel Temp Volts Oil Pressure
6 Gauge Set With Senders 200mph 300kph Speedo Tacho Fuel Temp Volts Oil Pressure
6 Gauge Set With Senders 200mph 300kph Speedo Tacho Fuel Temp Volts Oil Pressure
6 Gauge Set With Senders 200mph 300kph Speedo Tacho Fuel Temp Volts Oil Pressure
6 Gauge Set With Senders 200mph 300kph Speedo Tacho Fuel Temp Volts Oil Pressure

6 Gauge Set With Senders 200mph 300kph Speedo Tacho Fuel Temp Volts Oil Pressure

Specification: Fit For:Car, Truck, Motorcycle ATV UTV Marine Face Color:white Bezel Materials:Stainless Steel Grade Of Protection :IP67 Package Method :Neutral Box Speedometer and tachometer: Operating Voltage:9-32VDC Operating Current:? Install Diameter: 85mm(3-3 / 8") Backlight:Red This tacho must be hooked up to the "W terminal on vehicle alternator. Many diesel engines and most inboard gas boat engine alternator have this connection.

It can also be working with speed sender flying wheel, ECU or hei distributor. Minor gauges: Install Diameter: 52mm/(2-1/16) Input Ranges Oil Pressure: 10184ohms, 0-145 PSI/0-10bar Fuel Level: 240-33 ohms, E - F Water Temperature: 287.422.4 ohms, 100-250F Volt: 8-16V.

6 Gauge set with senders: GPS 200MPH 300KPH Speedometer, Tachometer, Fuel, Temp, Volts, O. Il Pressure, Fuel Level Sender, Water Temperature Sender, Oil Pressure Sender.

Fit For:Car Truck Motorcycle ATV UTV Marine Boat Yacht. Indicating range: 200MPH 300KPH Odometer Features. Backlight:LED backlight, Red color at night.

This tacho must be hooked up to the "W" terminal on vehicle alternator. It can also be working with tachometer sender or hei distributor. For details, see individual gauge description at link below. Install Diameter: 52mm/(2-1/16) mounting holes, screw on. Fuel : 240-33 ohm, E - F. If you need other output signals, like 10-180ohms, 0-90ohms ect, Leave me a note. Temp:287.4-22.4ohm, 100-250F.

Fuel Level Sender:240-33ohm, 6-1/2. We can DIY the length per your needs, but it will charge you extra funds if you need longer than 6.5inch, Send us a message before you paid. Attention: A minimum 1"clearance must be maintained between the tank bottom and the float retaining collar in a plastic tank and 1/2"clearance in a rigid metal tank. Senders can be used with all gauges brands that have compatible ohms.

Water Temperature Sender:287.4-22.4ohm 100-250F. Oil Pressure Sender:10184ohm, 0-145PSI. All messages be reply within 24hours. Welcome for wholesales trading, thank you!


6 Gauge Set With Senders 200mph 300kph Speedo Tacho Fuel Temp Volts Oil Pressure
